Model NO.
BG-PTFE
Cartridge Filter
Non-Woven Polyester Fiber
Filter Bag Filter
The Filter Type
Type
Pocket Filter
Usage
Dust Filter, Air Filter
Filtration Grade
HEPA Filter
Filter Bag Sectional Shape
Round Bag
Filter Bag Environment
Room Temperature
Cartridge Installation
Vertical Lifting
Product Name
PTFE Filter Cloth
Certificate
ISO9001, ISO14001
Working Temperature
90-130ºC
Application Areas
Power Plants, Cement, Chemicals
Thickness
1.6mm
Technology
Spunlace
Size/Specification
Customizable
Weightweight
550g
Transport Package
Industrial Carton or Customized
Specification
Customization
Trademark
Customization
Origin
China
HS Code
8421999090
Production Capacity
8000 Pieces/Day
Product Description
| Material | PTFE |
| Weight | 550g |
| Thickness | 1.8±20%mm |
| Fabric Structure | Spunlace |
| Continuous Operating Temperature | 90-130ºC |
| Maximum Temperature | 150ºC |
| Mean Air Permeability m3/m2/min | 2-5 |
| Breaking Strength-MD N / 5cm | ≥1000 |
| Breaking Strength-CMD N / 5cm | ≥1300 |
| Breaking Elongation( N/5cm)-MD | ≤30% |
| Breaking Elongation( N/5cm)-CMD | ≤50% |
| Wear Resistance | Good |
| Acid Resistance | Excellent |
| Alkali Resistance | Good |
| Filtration Performance | Excellent |
| Application Range | Cement Kiln Head And Tail, Asphalt Mixing |
| Size/Specification | Customization |
