No. Model.
TSS380C-HW
Anti-theft alarm system type
Smoke alarm
Anti-theft alarm system distance
Popular detectors
Types of smoke detectors
Photoelectric smoke type
Install infrared sensor
Ceiling
certificate
ce, ukca, rohs, reach, iso9001, bsci
machine type
electronic smoke alarm
authenticate
certified to en14604:2005/ac:2008
power source
2*1.5v AA input
battery power consumption
Low power consumption, replaceable AA battery
battery life
Two year battery life
Shipping Package
cardboard
Specifications
white
Brand
jbe
Origin
Zhejiang, China
Production Capacity
100000 packages/month
| Power supply | 2*1.5V AA type | Low voltage threshold | ≤ 2.6V |
| Activity stream | ≤ 8uA | Quiet now. | 8 minutes |
| Warning sensitivity | 0.10 -0,16dB/m | Product Lifespan | >10 years |
| Compliance with standards | EN14604:2005/AC:2008 | Humidity range | <93% relative humidity (RH) |
| Warning line | ≤ 60mA | Temperature range | 0ºC to 40ºC |
| Alarm volume | >85dB(A) @ 3 meters. | Size | 120mm diameter x 36.6mm depth |
| Audio sample | (BI 0.5s - pause 0.5s - BI 0.5s - pause 0.5s - BI 0.5s - pause 1.5s, with RED LED, repeat this alarm pattern) | ||
| Smoke detection status | Normal | Note |
| Smoke Fire | ||
| Smoke error | ||
| 8 minutes silence | ||
| Power status | Normal | Normal battery |
| Low battery voltage | Battery voltage lower than 2.6 V | |
| Smoke concentration ratio | 0%/25%/50%/75%/100%/125%/150%/175% | When the smoke detection value displays to 100%, it will enter the alarm state; |
| /200%/225%/250%/255% |
