Model NO.
IGE-4000I
Type
Micro-Computer Control Automatic Diesel Generator
Installation Method
Portable
Stroke
Four Stroke
Cooling Method
Air Cooled
Output Type
AC Single Phase
Speed
Speed
Conditions of Use
Land Use
Usage
Common Units, Standby Unit, Emergency Crew
Landuse Type of Unit
Automation Type
Excitation Mode
AC Rotating Exciter
Rated Voltage
110, 120, 220, 230, 240
Machine Dimension
480 X 410 X 490 mm
Transport Package
Carton
Trademark
TOKING AUTONIKPOWER
Origin
China
HS Code
8502200000
Production Capacity
500000/Year
Product Description
| Rated out put/Max out put: | 3500W/4000W |
| AC output: | 2*120V or 2*230 V~ (AC) |
| DC output: | 1 x 12 VDC (8.3A) or (USB 5VDC2.1A) |
| AC frequency: | 50 Hz/60Hz |
| Overload protection: | Yes |
| Oil deficiency safety device: | Yes |
| Engine Model: | LY170F. Single-cylinder, 4 stroke petrol engine,air-cooled gasoline engine |
| Output max.: | 7.0 HP |
| Displacement: | 212 cc |
| Power/ Speed( kW/r/min): | 4.5/ 3600 |
| Fuel: | unleaded gasoline |
| Continuous Working Hours: | 7H |
| Starter: | Recoil starter |
| Operating Noise (7m) dB: | 60-63dB |
| Tank volume: | 12 L |
| Fuel consumption: | 1.6L/h |
| Dimensions L x W x H: | 480 x 410 x 490 mm |
